LOL-WAL-0062

Surface Mounted Downlight

Application: Wall

The LOL-WAL-0062 is suitable for mounting on timber masonry stone etc. non-adjustable for one way wall washing. It can be mounted with the lamp directed up or down. Body and base CNC machined or hand spun from either Aluminium or Copper or Stainless Steel.

IP66

Dimensions

  • 240V Back Plate

    100L x 78Ø x 90H

  • 12V Back Plate

    96L x 78Ø x 90H

Power Input

    12V AC, 240V

Lamp details

  • Lamp LED Module

Power usage

    4W-7W

Beam Angles

    15, 25, 38, 60

Colour Temperature

    3000k

Lumen

    600lm

CRI

    90+

Finish type

  • Copper
  • Stainless Steel
  • Powdercoat Aluminium

Accessories

3000k

General Notes & Installation

Note: All dimensions and other specifications can change without notice. Please contact Light on Landscape to confirm the availability and current specifications of this luminaire. Installation: Light on Landscape strongly recommend that all luminaires be correctly installed and maintained. Failure to do so will result in the voiding of the manufacturer's warranty and the reduced efficiency, performance and life of the fixture. To eliminate voltage drop, we advise that the recommended UV stabilized cable and run lengths are used, along with soldered joins, heat shrink connectors and quality lamps.

Mounting

Surface Mount
