LOL-PAT-0165

Compact height path light

Application: Path

For accenting low flower beds or illuminating pathways this low voltage path light fixture suitable for low ground cover and stepping stones. LOL-PAT-0165 has simple and tool-free maintenance. The stem is a heavy-gauge extruded solid brass pipe with a threaded base. The lens is frosted, optical quality Pyrex to safeguard the lamp and optics.

Reduced Glare

Dimensions

  • Type 1

    419H x 35D x 89Ø

  • Type 2

    419H x 35D x 114Ø

Power Input

    24V AC DC, 12V

Lamp details

  • Lamp Bi- Pin G4

Power usage

    1.5W, 2.5W

Beam Angles

    360

Colour Temperature

    Warm White

Finish type

  • Aged Copper Brass
  • Brushed Brass

Important notes

The brushed copper mantle will rapidly age to an elegant rich bronze-like color and may develop areas of patina over time.

General Notes & Installation

Note: All dimensions and other specifications can change without notice. Please contact Light on Landscape to confirm the availability and current specifications of this luminaire. Installation: Light on Landscape strongly recommend that all luminaires be correctly installed and maintained. Failure to do so will result in the voiding of the manufacturer's warranty and the reduced efficiency, performance and life of the fixture. To eliminate voltage drop, we advise that the recommended UV stabilized cable and run lengths are used, along with soldered joins, heat shrink connectors and quality lamps.

Mounting

Fixture may be mounted into threaded hubs in junction boxes or threaded spikes or floor-mounting canopies.
