LOL-PAT-0032

Adjustable Head Path Light

Application: Path

The LOL-PAT-0032 is a versatile and powerful this low voltage fixture suitable for both path and accent lighting. It is constructed of die-cast copper-free aluminum for strength and reliability. The fully rotatable shroud is fitted with a silicone o-ring gasket to ensure a superior weather-tight seal. A clear or frosted convex glass lens safeguards the lamp and optics. The fully adjustable knuckle is made from injection-molded fibre-reinforced composite which helps isolate the fixture from corrosive soil.

Dimensions

  • 272L x 57C x 646H

Power Input

    24V AC DC, 12V

Lamp details

  • Lamp MR16

Power usage

    5W-7W

Beam Angles

    TBA

Colour Temperature

    Warm White

Lumen

    TBA

CRI

    TBA

Dimming system

  • Call to discuss

Finish type

  • Wide range of Powdercoat colurs on Aluminium - Copper Free

Accessories

Tree mount junction box or wall mount canopy options available

General Notes & Installation

Note: All dimensions and other specifications can change without notice. Please contact Light on Landscape to confirm the availability and current specifications of this luminaire. Installation: Light on Landscape strongly recommend that all luminaires be correctly installed and maintained. Failure to do so will result in the voiding of the manufacturer's warranty and the reduced efficiency, performance and life of the fixture. To eliminate voltage drop, we advise that the recommended UV stabilized cable and run lengths are used, along with soldered joins, heat shrink connectors and quality lamps.

Mounting

Spike Mount
