LOL-ING-0288

Symmetrical Recessed Uplight

Application: Inground

The LOL-ING-0288 is a high quality and practical luminaire with contemporary styling.

Reduced Glare Low Profile IP 68 Joining Kit IP68

Dimensions

  • Type 1

    58 Ø x 71.5HType 2

  • Type 2

    43 Ø x 42H

  • Type 3

    53W x 53L

  • Type 4

    42W x 42L

  • High Pressure Pipe

    50 Ø x 200L

Power Input

    12V AC, Series, 700mA Constant Remote

Lamp details

  • Lamp LED Module

Power usage

    1W, 2W, 4W

Beam Angles

    10, 12, 15, 20, 26, 30, 36, 74, 8

Colour Temperature

    Warm White

Lumen

    60-240 lm

CRI

    80+

Finish type

  • 316 Stainless Steel
  • Black Anodised Aluminium
  • Natural Copper

Important notes

* efficacy 60Lm/W.** Connect remote driver versions in series and integral driver versions in parallel.*** hex cell baffle available**** wide flange - 75mm diameter option available for circular types

General Notes & Installation

Note: All dimensions and other specifications can change without notice. Please contact Light on Landscape to confirm the availability and current specifications of this luminaire. Installation: Light on Landscape strongly recommend that all luminaires be correctly installed and maintained. Failure to do so will result in the voiding of the manufacturer's warranty and the reduced efficiency, performance and life of the fixture. To eliminate voltage drop, we advise that the recommended UV stabilized cable and run lengths are used, along with soldered joins, heat shrink connectors and quality lamps.

Mounting

Installation in soil or concrete requires 50mm conduit.
